OAV ROLLENLUFTLAGER
Ultra-Hochpräzisions-Luftlager, Bühnen, Komponenten, Bewegungssysteme
Frictionless web handling for ultra-sensitive materials in roll-to-roll processing.
​
-
Zero contact, zero surface damage
-
Porous graphite air film technology
-
Frictionless tension control
-
Custom diameter and lengths available
Teilenummer OAVCB6060
Teilenummer OAVCB6060
Air is distributed through porous graphite to create a uniform non-contact support layer between the roller and web material.
This eliminates friction, reduces particulate contamination, and maintains consistent web tension.
Teilenummer OAVCB6060
-
Semiconductor Wafer Handling
-
Lithium Battery Film Processing
-
Optical Film Manufacturing
-
Flexible Electronics
-
Precision Coating Lines
Teilenummer OAVCB6060
-
Eliminates Scratching and Deformation
-
No Lubrication Required
-
Cleanroom Compatible
-
High-Speed Web Stability
-
Long-Service Life
Teilenummer OAVCB6060
Used in aerospace, semiconductor, and advanced manufacturing applications requiring micron-level precision motion control.
OAV ROLLENLUFTLAGER
Engineered for the Most Demanding Applications
The OAV-AT75600 eliminates contact, friction, and contamination, protecting delicate materials and coatings across advanced manufacturing processes.
Flexible Electronics
& Displays
Protects OLED, QLED, flexible PCB's, and printed electronics during coating, lamination, and inspection.
Optical & Display Film
Prevents scratches on polarizers, AR coatings, waveguides, and other optical precision films.
Membranes & Filtration Media
Handles delicate separator films, RO membranes, and fuel cell membranes without compression marks or surface damage.
Battery Manufacturing
Preserved electrode coatings and separators, preventing cracks, shedding, and edge damage.
Wet & Freshly Coated Webs
Safely transports webs immediately after coating without marring uncured or tacky surfaces.
Specialty Films & Foils
Ideal for ultrathin metal foils, graphene films, and embossed materials where pressure would deform features.
Photovoltaics
Ideal for thin-film solar and delicate substrates where contact can damage active layers.
Medical & Cleanroom Applications
Maintains contamination-free handling for pharmaceutical films, patches, and diagnostic materials.
Web Inspection & Metrology
Stabilizes webs for accurate scanning without vibration, rollers marks, or measurement interference.
